End Mills
Solid carbide corner rounding cutters
- Diameter range
- Ø 6–10 mm
- Sizes
- 11 sizes
- Flutes (Z)
- 4
- Coating
- nACo Multilayer
- Helix angle
- 0°
- Standard
- Toolex drill standard
Images
Product images
Click to enlarge
Code key
Specifications
The icons describe the family's reference size in the order of the Toolex article code.
Type
Corner rounding cutter
Grade
NG-10
Reference diameter
Ø 3.5 mm
Standard
Toolex drill standard
Flutes
4 flutes
Shank type
DIN 6535 HA
Flute length
3 mm
Helix angle
0°
Edge form
Radius (35)
Coating
nACo Multilayer
Overall length
92 mm
Sizes
Size table
All dimensions in mm; column headings match the symbols on the technical drawing. Add any row to your quote basket by its article code.
Article code for quote
11 sizes
Download Excel| Quote | |||||||
|---|---|---|---|---|---|---|---|
| 0.5 | 7 | 63 | 8 | 4 | IS0050T4C07G05B063 | IS0050T4C07G05N063 | |
| 1 | 6 | 63 | 8 | 4 | IS0100T4C06G10B063 | IS0100T4C06G10N063 | |
| 1.5 | 7 | 72 | 10 | 4 | IS0150T4C07G15B072 | IS0150T4C07G15N072 | |
| 2 | 6 | 83 | 10 | 4 | IS0200T4C06G20B083 | IS0200T4C06G20N083 | |
| 2.5 | 7 | 83 | 12 | 4 | IS0250T4C07G25B083 | IS0250T4C07G25N083 | |
| 3 | 6 | 83 | 12 | 4 | IS0300T4C06G30B083 | IS0300T4C06G30N083 | |
| 3.5 | 9 | 92 | 16 | 4 | IS0350T4C09G35B092 | IS0350T4C09G35N092 | |
| 4 | 8 | 92 | 16 | 4 | IS0400T4C08G40B092 | IS0400T4C08G40N092 | |
| 4.5 | 7 | 92 | 16 | 4 | IS0450T4C07G45B092 | IS0450T4C07G45N092 | |
| 5 | 10 | 104 | 20 | 4 | IS0500T4C10G50B104 | IS0500T4C10G50N104 | |
| 6 | 8 | 104 | 20 | 4 | IS0600T4C08G60B104 | IS0600T4C08G60N104 |
